Background

An ONNX Runtime Execution Provider (EP) executes model operations on one or more hardware accelerators (e.g., GPU, NPU, etc.). ONNX Runtime provides a variety of built-in EPs, such as the default CPU EP. To enable further extensibility, ONNX Runtime supports user-defined plugin EP libraries that an application can register with ONNX Runtime for use in an ONNX Runtime inference session.

This page provides a reference for the APIs necessary to develop and use plugin EP libraries with ONNX Runtime.

Creating a plugin EP library

A plugin EP is built as a dynamic/shared library that exports the functions CreateEpFactories() and ReleaseEpFactory(). ONNX Runtime calls CreateEpFactories() to obtain one or more instances of OrtEpFactory. An OrtEpFactory creates OrtEp instances and specifies the hardware devices supported by the EPs it creates.

The ONNX Runtime repository includes a sample plugin EP library, which is referenced in the following sections.

Defining an OrtEp

An OrtEp represents an instance of an EP that is used by an ONNX Runtime session to identify and execute the model operations supported by the EP.

The following table lists the required variables and functions that an implementer must define for an OrtEp.

Field	Summary	Example implementation
ort_version_supported	The ONNX Runtime version with which the EP was compiled. Implementation should set to `ORT_API_VERSION`.	ExampleEp()
GetName	Get the execution provider name.	ExampleEp::GetNameImpl()
GetCapability	Get information about the nodes/subgraphs supported by the `OrtEp` instance.	ExampleEp::GetCapabilityImpl()
Compile	Compile `OrtGraph` instances assigned to the `OrtEp`. Implementation must set a `OrtNodeComputeInfo` instance for each `OrtGraph` in order to define its computation function. If the session is configured to generate a pre-compiled model, the execution provider must return `count` number of EPContext nodes.	ExampleEp::CompileImpl()
ReleaseNodeComputeInfos	Release `OrtNodeComputeInfo` instances.	ExampleEp::ReleaseNodeComputeInfosImpl()

The following table lists the optional functions that an implementor may define for an OrtEp. If an optional OrtEp function is not defined, ONNX Runtime uses a default implementation.

Field	Summary	Example implementation
GetPreferredDataLayout	Get the EP's preferred data layout. If this function is not implemented, ORT assumes that the EP prefers the data layout `OrtEpDataLayout::NCHW`.
ShouldConvertDataLayoutForOp	Given an op with domain `domain` and type `op_type`, determine whether an associated node's data layout should be converted to a `target_data_layout`. If the EP prefers a non-default data layout, this function will be called during layout transformation with `target_data_layout` set to the EP's preferred data layout Implementation of this function is optional. If an EP prefers a non-default data layout, it may implement this to customize the specific op data layout preferences at a finer granularity.
SetDynamicOptions	Set dynamic options on this EP. Dynamic options can be set by the application at any time after session creation with `OrtApi::SetEpDynamicOptions()`. Implementation of this function is optional. An EP should only implement this function if it needs to handle any dynamic options.
OnRunStart	Called by ORT to notify the EP of the start of a run. Implementation of this function is optional. An EP should only implement this function if it needs to handle application-provided options at the start of a run.
OnRunEnd	Called by ORT to notify the EP of the end of a run. Implementation of this function is optional. An EP should only implement this function if it needs to handle application-provided options at the end of a run.
CreateAllocator	Create an `OrtAllocator` for the given `OrtMemoryInfo` for an `OrtSession`. The `OrtMemoryInfo` instance will match one of the values set in the `OrtEpDevice` using `EpDevice_AddAllocatorInfo`. Any allocator specific options should be read from the session options. Implementation of this function is optional. If not provided, ORT will use `OrtEpFactory::CreateAllocator()`.
CreateSyncStreamForDevice	Create a synchronization stream for the given memory device for an `OrtSession`. This is used to create a synchronization stream for the execution provider and is used to synchronize operations on the device during model execution. Any stream specific options should be read from the session options. Implementation of this function is optional. If not provided, ORT will use `OrtEpFactory::CreateSyncStreamForDevice()`.
GetCompiledModelCompatibilityInfo	Get a string with details about the EP stack used to produce a compiled model. The compatibility information string can be used with `OrtEpFactory::ValidateCompiledModelCompatibilityInfo` to determine if a compiled model is compatible with the EP.

Defining an OrtEpFactory

An OrtEpFactory represents an instance of an EP factory that is used by an ONNX Runtime session to query device support, create allocators, create data transfer objects, and create instances of an EP (i.e., an OrtEp).

The following table lists the required variables and functions that an implementer must define for an OrtEpFactory.

Field	Summary	Example implementation
ort_version_supported	The ONNX Runtime version with which the EP was compiled. Implementation should set this to `ORT_API_VERSION`.	ExampleEpFactory()
GetName	Get the name of the EP that the factory creates. Must match `OrtEp::GetName()`.	ExampleEpFactory::GetNameImpl()
GetVendor	Get the name of the name of the vendor that owns the EP that the factory creates.	ExampleEpFactory::GetVendor()
GetVendorId	Get the vendor ID of the vendor that owns the EP that the factory creates. This is typically the PCI vendor ID.	ExampleEpFactory::GetVendorId()
GetVersion	Get the version of the EP that the factory creates. The version string should adhere to the Semantic Versioning 2.0 specification.	ExampleEpFactory::GetVersionImpl()
GetSupportedDevices	Get information about the `OrtHardwareDevice` instances supported by an EP created by the factory.	ExampleEpFactory::GetSupportedDevicesImpl()
CreateEp	Creates an `OrtEp` instance for use in an ONNX Runtime session. ORT calls `OrtEpFactory::ReleaseEp()` to release the instance.	ExampleEpFactory::CreateEpImpl()

The following table lists the optional functions that an implementer may define for an OrtEpFactory.

Field	Summary	Example implementation
ValidateCompiledModelCompatibilityInfo	Validate the compatibility of a compiled model with the EP. This function validates if a model produced with the supllied compatibility information string is supported by the underlying EP. The implementation should check if a compiled model is compatible with the EP and return the appropriate `OrtCompiledModelCompatibility` value.
CreateAllocator	Create an `OrtAllocator` that can be shared across sessions for the given `OrtMemoryInfo`. The factory that creates the EP is responsible for providing the allocators required by the EP. The `OrtMemoryInfo` instance will match one of the values set in the `OrtEpDevice` using `EpDevice_AddAllocatorInfo`.	ExampleEpFactory::CreateAllocatorImpl()
ReleaseAllocator	Releases an `OrtAllocator` instance created by the factory.	ExampleEpFactory::ReleaseAllocatorImpl()
CreateDataTransfer	Creates an `OrtDataTransferImpl` instance for the factory. An `OrtDataTransferImpl` can be used to copy data between devices that the EP supports.	ExampleEpFactory::CreateDataTransferImpl()
IsStreamAware	Returns true if the EPs created by the factory are stream-aware.	ExampleEpFactory::IsStreamAwareImpl()
CreateSyncStreamForDevice	Creates a synchronization stream for the given `OrtMemoryDevice`. This is use to create a synchronization stream for the `OrtMemoryDevice` that can be used for operations outside of a session.	ExampleEpFactory::CreateSyncStreamForDeviceImpl()

Exporting functions to create and release factories

ONNX Runtime expects a plugin EP library to export certain functions/symbols. The following table lists the functions that have to be exported from the plugin EP library.

Function	Description	Example implementation
CreateEpFactories	ONNX Runtime calls this function to create `OrtEpFactory` instances.	ExampleEp: CreateEpFactories
ReleaseEpFactory	ONNX Runtime calls this function to release an `OrtEpFactory` instance.	ExampleEp: ReleaseEpFactory

Using a plugin EP library

Plugin EP library registration

The sample application code below uses the following API functions to register and unregister a plugin EP library.

const char* lib_registration_name = "ep_lib_name";
Ort::Env env;

// Register plugin EP library with ONNX Runtime.
env.RegisterExecutionProviderLibrary(
  lib_registration_name,   // Registration name can be anything the application chooses.
  ORT_TSTR("ep_path.dll")  // Path to the plugin EP library.
);

{
  Ort::Session session(env, /*...*/);
  // Run a model ...
}

// Unregister the library using the application-specified registration name.
// Must only unregister a library after all sessions that use the library have been released.
env.UnregisterExecutionProviderLibrary(lib_registration_name);

As shown in the following sequence diagram, registering a plugin EP library causes ONNX Runtime to load the library and call the library’s CreateEpFactories() function. During the call to CreateEpFactories(), ONNX Runtime determines the subset of hardware devices supported by each factory by calling OrtEpFactory::GetSupportedDevices() with all hardware devices that ONNX Runtime discovered during initialization.

The factory returns OrtEpDevice instances from OrtEpFactory::GetSupportedDevices(). Each OrtEpDevice instance pairs a factory with a hardware device that the factory supports. For example, if a single factory instance supports both CPU and NPU, then the call to OrtEpFactory::GetSupportedDevices() returns two OrtEpDevice instances:

ep_device_0: (factory_0, CPU)
ep_device_1: (factory_0, NPU)

Sequence diagram showing registration and unregistration of a plugin EP library

Session creation with explicit OrtEpDevice(s)

The application code below uses the API function SessionOptionsAppendExecutionProvider_V2 to add an EP from a library to an ONNX Runtime session.

The application first calls GetEpDevices to get a list of OrtEpDevices available to the application. Each OrtEpDevice represents a hardware device supported by an OrtEpFactory. The SessionOptionsAppendExecutionProvider_V2 function takes an array of OrtEpDevice instances as input, where all OrtEpDevice instances refer to the same OrtEpFactory.

Ort::Env env;
env.RegisterExecutionProviderLibrary(/*...*/);

{
  std::vector<Ort::ConstEpDevice> ep_devices = env.GetEpDevices();

  // Find the Ort::EpDevice for "my_ep".
  std::array<Ort::ConstEpDevice, 1> selected_ep_devices = { nullptr };
  for (Ort::ConstEpDevice ep_device : ep_devices) {
    if (std::strcmp(ep_device.GetName(), "my_ep") == 0) {
      selected_ep_devices[0] = ep_device;
      break;
    }
  }

  if (selected_ep_devices[0] == nullptr) {
    // Did not find EP. Report application error ...
  }

  Ort::KeyValuePairs ep_options(/*...*/);  // Optional EP options.
  Ort::SessionOptions session_options;
  session_options.AppendExecutionProvider_V2(env, selected_ep_devices, ep_options);

  Ort::Session session(env, ORT_TSTR("model.onnx"), session_options);

  // Run model ...
}

env.UnregisterExecutionProviderLibrary(/*...*/);

As shown in the following sequence diagram, ONNX Runtime calls OrtEpFactory::CreateEp() during session creation in order to create an instance of the plugin EP.

Sequence diagram showing session creation with explicit ep devices

Session creation with automatic EP selection

The application code below uses the API function SessionOptionsSetEpSelectionPolicy to have ONNX Runtime automatically select an EP based on the user’s policy (e.g., PREFER_NPU). If the plugin EP library registered with ONNX Runtime has a factory that supports NPU, then ONNX Runtime may select an EP from that factory to run the model.

Ort::Env env;
env.RegisterExecutionProviderLibrary(/*...*/);

{
  Ort::SessionOptions session_options;
  session_options.SetEpSelectionPolicy(OrtExecutionProviderDevicePolicy::PREFER_NPU);

  Ort::Session session(env, ORT_TSTR("model.onnx"), session_options);

  // Run model ...
}

env.UnregisterExecutionProviderLibrary(/*...*/);

Sequence diagram showing session creation with automatic EP selection

API reference

API header files:

onnxruntime_ep_c_api.h
- Defines interfaces implemented by plugin EP and EP factory instances.
- Provides APIs utilized by plugin EP and EP factory instances.
onnxruntime_c_api.h
- Provides APIs used to traverse an input model graph.

Data Types

Type	Description
OrtHardwareDeviceType	Enumerates classes of hardware devices: OrtHardwareDeviceType_CPU OrtHardwareDeviceType_GPU OrtHardwareDeviceType_NPU
OrtHardwareDevice	Opaque type that represents a physical hardware device.
OrtExecutionProviderDevicePolicy	Enumerates the default EP selection policies available to users of ORT's automatic EP selection.
OrtEpDevice	Opaque type that represents a pairing of an EP and hardware device that can run a model or model subgraph.
OrtNodeFusionOptions	Struct that contains options for fusing nodes supported by an EP.
OrtNodeComputeContext	Opaque type that contains a compiled/fused node's name and host memory allocation functions. ONNX Runtime provides an instance of `OrtNodeComputeContext` as an argument to `OrtNodeComputeInfo::CreateState()`.
OrtNodeComputeInfo	Struct that contains the computation function for a compiled `OrtGraph` instance. Initialized by an `OrtEp` instance.
OrtEpGraphSupportInfo	Opaque type that contains information on the nodes supported by an EP. An instance of `OrtEpGraphSupportInfo` is passed to `OrtEp::GetCapability()` and the EP populates the `OrtEpGraphSupportInfo` instance with information on the nodes that it supports.
OrtEpDataLayout	Enumerates the operator data layouts that could be preferred by an EP. By default, ONNX models use a "channel-first" layout (e.g., NCHW) but some EPs may prefer a "channel-last" layout (e.g., NHWC).
OrtMemoryDevice	Opaque type that represents a combination of a physical device and memory type. A memory allocation and allocator are associated with a specific `OrtMemoryDevice`, and this information is used to determine when data transfer is required.
OrtDataTransferImpl	Struct of functions that an EP implements to copy data between the devices that the EP uses and CPU.
OrtSyncNotificationImpl	Struct of functions that an EP implements for Stream notifications.
OrtSyncStreamImpl	Struct of functions that an EP implements if it needs to support Streams.
OrtEpFactory	A plugin EP library provides ORT with one or more instances of `OrtEpFactory`. An `OrtEpFactory` implements functions that are used by ORT to query device support, create allocators, create data transfer objects, and create instances of an EP (i.e., an `OrtEp` instance). An `OrtEpFactory` may support more than one hardware device (`OrtHardwareDevice`). If more than one hardware device is supported by the factory, an EP instance created by the factory is expected to internally partition any graph nodes assigned to the EP among its supported hardware devices. Alternatively, if an EP library author needs ONNX Runtime to partition the graph nodes among different hardware devices supported by the EP library, then the EP library must provide multiple `OrtEpFactory` instances. Each `OrtEpFactory` instance must support one hardware device and must create an EP instance with a unique name (e.g., MyEP_CPU, MyEP_GPU, MyEP_NPU).
OrtEp	An instance of an Ep that can execute model nodes on one or more hardware devices (`OrtHardwareDevice`). An `OrtEp` implements functions that are used by ORT to query graph node support, compile supported nodes, query preferred data layout, set run options, etc. An `OrtEpFactory` creates an `OrtEp` instance via the `OrtEpFactory::CreateEp()` function.
OrtRunOptions	Opaque object containing options passed to the `OrtApi::Run()` function, which runs a model.
OrtGraph	Opaque type that represents a graph. Provided to `OrtEp` instances in calls to `OrtEp::GetCapability()` and `OrtEp::Compile()`.
OrtValueInfo	Opaque type that contains information for a value in a graph. A graph value can be a graph input, graph output, graph initializer, node input, or node output. An `OrtValueInfo` instance has the following information. Type and shape (e.g., `OrtTypeInfo`) `OrtNode` consumers `OrtNode` producer Information that classifies the value as a graph input, graph output, initializer, etc.
OrtExternalInitializerInfo	Opaque type that contains information for an initializer stored in an external file. An `OrtExternalInitializerInfo` instance contains the file path, file offset, and byte size for the initializer. Can be obtained from an `OrtValueInfo` via the function `ValueInfo_GetExternalInitializerInfo()`.
OrtTypeInfo	Opaque type that contains the element type and shape information for ONNX tensors, sequences, maps, sparse tensors, etc.
OrtTensorTypeAndShapeInfo	Opaque type that contains the element type and shape information for an ONNX tensor.
OrtNode	Opaque type that represents a node in a graph.
OrtOpAttrType	Enumerates attribute types.
OrtOpAttr	Opaque type that represents an ONNX operator attribute.

Plugin EP Library Registration APIs

The following table lists the API functions used for registration of a plugin EP library.

Function	Description
RegisterExecutionProviderLibrary	Register an EP library with ORT. The library must export the `CreateEpFactories` and `ReleaseEpFactory` functions.
UnregisterExecutionProviderLibrary	Unregister an EP library with ORT. Caller MUST ensure there are no `OrtSession` instances using the EPs created by the library before calling this function.
GetEpDevices	Get the list of available OrtEpDevice instances. Each `OrtEpDevice` instance contains details of the execution provider and the device it will use.
SessionOptionsAppendExecutionProvider_V2	Append the execution provider that is responsible for the provided `OrtEpDevice` instances to the session options.
SessionOptionsSetEpSelectionPolicy	Set the execution provider selection policy for the session. Allows users to specify a device selection policy for automatic EP selection. If custom selection is required please use `SessionOptionsSetEpSelectionPolicyDelegate` instead.
SessionOptionsSetEpSelectionPolicyDelegate	Set the execution provider selection policy delegate for the session. Allows users to provide a custom device selection policy for automatic EP selection.
